DIN3202 F4 F5 Water gate valve DN20 DN50 Ductile Iron Soft Sealing Threaded Gate Valve PN16DIN3202 F4 F5 Water gate valve DN20 DN50 Ductile Iron Soft Sealing Threaded Gate Valve PN16DIN3202 F4 F5 Water gate valve DN20 DN50 Ductile Iron Soft Sealing Threaded Gate Valve PN16

DIN3202 F4 F5 Water gate valve DN20 DN50 Ductile Iron Soft Sealing Threaded Gate Valve PN16

  • Series: Sasquatch Series Resilient Seated Gate Valve
  • Port size: DN20 - DN50
  • Pressure rating: PN10, PN16
  • Temperature: ≤ 80°C
  • Connection: Threaded
  • Medium:Water
  • Face to Face:BS5163, DIN3202 F4, F5
  • Valve body: Ductile iron:GGG50
  • Disc material: GGG40 + EPDM,Ductile iron coated with EPDM
  • Seat: EPDM
  • Coating: 150-250μm epoxy powder coating
  • Certificate: CE ,WRAS,API,OHSAS18001:2007,ISO9001:2015

Low pressure drop and 100% watertight, low torque.
Size range: DN20, DN25, DN32, DN40, DN50
Wedge core: brass for DN20-32, DI for DN40-50



· Threaded connection, BSPP, BSPT, NPT
· 100% sealing test
· 100% tightness Bi-directional flow.
· Low pressure drop.
· Detachable in load.
· Screws protected against external dirts WRAS approved for potable water upon request.

·  Hydraulic tests according to EN-12266-1,Class A
· Designed to EN1074-2
· BSP threads to EN10226/1 or EN ISO 228-1 G thread NPT threads upon request



Size G (inch) BSP thread L (mm) end-end H (mm) P (mm) Torque (N.m)
DN20 3/4" 95 145 27 15N.m
DN25 1" 105 145 30 15N.m
DN32 1 1/4" 120 150 32 15N.m
DN40 1 1/2" 130 202 37 30N.m
DN50 2" 150 197 45 30N.m



Ⅰ Business area: fluid control products, technology and environmental protection products.

Ⅱ Advanced CNC machining centers, professional process cells, wide-range welding equipment, automatic assembly lines and coating.

Ⅲ China's standard reference unit, to participate in the development of relevant valve industry standards.

Ⅳ We have set up a research and development center in Houston, Texas, in the United States.

Ⅴ Product Standard: GB, German Standard, American Standard, TUV CE, ISO 9001, ADWO-2000, TS, PED, WRC WRAS, KTW, API 6D, API609.

VI Main production: butterfly valve, ball valve, gate valve, check valve, globe valves, pipe fittings, manual / pneumatic / electric actuator, valve parts.





FAQ

Q: If I need quotation, what informations do we need?
A: Valves' materials, Temperature, Pressure, Medium, Appllication System.

Q: Can you provide actuators, what you have?
A: Pneumatic, Electric, Hrdraulic, Solenoid Valves. RKSfluid actuators adopt USA technology. Which you need, just tell us.

Q: What's your productive capacity?
A: RKSfluid has four plants that can provide the products you need.

Q: Production lead time
A: Normal products have stock in 2~5 working days. Customized base on your need.

Q: MOQ
A: 1pc for all products.

Q: How about the quality assurance?
A: 100% quality test before delivery, 2 years warranty. Ensure your system working safety.
   We got TUV, API, WRAS, CE, ISO certification.
   Standard conform to DIN, ASME, BS EN, JIS, API, AWWA.

Q: How could you provide quality service to our customers?
A: RKSfluid own 27 years experiences and more than 70 R&D engineers provide technical support, model selection and installation guidance for you.
