MINOTAUR series replaceable seat high performance butterfly valve
Feature:
Applications
4F3F 3F2F model - Ductile Iron
Weights and Dimensions
| DN | ΦD(mm) | ΦK(mm) | N-Φd(mm) | Full Bore | Reduced Bore | |||||||||||
| PN10 | PN16 | PN25 | PN40 | PN10 | PN16 | PN25 | PN40 | PN10 | PN16 | PN25 | PN40 | H(mm) | PN16 Weight | H(mm) | PN16 Weight | |
| 50 | 165 | Φ125 | 4-Φ19 | 240 | 13 | - | - | |||||||||
| 65 | 185 | Φ145 | 4-Φ19 | 8-Φ19 | - | - | 240 | 13.5 | ||||||||
| 80 | 200 | Φ160 | 8-Φ19 | 330 | 15 | 240 | 14 | |||||||||
| 100 | 220 | 235 | Φ180 | Φ190 | 8-Φ19 | 8-Φ23 | 390 | 20 | 330 | 16 | ||||||
| 150 | 285 | 300 | Φ240 | Φ250 | 8-Φ23 | 8-Φ28 | 530 | 40 | 390 | 23 | ||||||
| 200 | 340 | 360 | 375 | Φ295 | Φ310 | Φ320 | 8-Φ23 | 12-Φ23 | 12-Φ28 | 12-Φ31 | 650 | 65 | 530 | 44 | ||
| 250 | 395 | 405 | 425 | 450 | Φ350 | Φ355 | Φ370 | Φ385 | 12-Φ23 | 12-Φ28 | 12-Φ31 | 12-Φ34 | 760 | 95 | 650 | 70 |
| 300 | 445 | 460 | 485 | 515 | Φ400 | Φ410 | Φ430 | Φ450 | 12-Φ23 | 12-Φ28 | 16-Φ31 | 16-Φ34 | 860 | 144 | 760 | 101 |
| 350 | 505 | 520 | 555 | 580 | Φ460 | Φ470 | Φ490 | Φ510 | 16-Φ23 | 16-Φ28 | 16-Φ34 | 16-Φ37 | - | - | 860 | 153 |
| 400 | 565 | 580 | 620 | 660 | Φ515 | Φ525 | Φ550 | Φ585 | 16-Φ28 | 16-Φ31 | 16-Φ37 | 16-Φ40 | - | - | 860 | 163 |
4F3F 3F2F model - Stainless Steel
For more information, please contact us.
Ⅰ Business area: fluid control products, technology and environmental protection products.
Ⅱ Advanced CNC machining centers, professional process cells, welding equipment, automatic assembly lines and coating.
Ⅲ China's standard reference unit, to participate in the development of relevant valve industry standards.
Ⅳ We have set up a research and development center in Houston, Texas, in the United States.
Ⅴ Product Standard: GB, German Standard, American Standard, TUV CE, ISO 9001, ADWO-2000, TS, PED, WRC WRAS, KTW, API 6D, API609.
VI Main production: butterfly valve, ball valve, gate valve, check valve, globe valves, pipe fittings, manual / pneumatic / electric actuator, valve parts.
FAQ:
Q: If I need quotation, what informations do we need?
A: Valves' materials, Temperature, Pressure, Medium, Appllication System.
Q: Can you provide actuators, what you have?
A: Pneumatic, Electric, Hrdraulic, Solenoid Valves. RKSfluid actuators adopt USA technology. Which you need, just tell us.
Q: What's your productive capacity?
A: RKSfluid has four plants that can provide the products you need.
Q: Production lead time
A: Normal products have stock in 2~5 working days. Customized base on your need.
Q: MOQ
A: 1pc for all products.
Q: How about the quality assurance?
A: 100% quality test before delivery, 2 years warranty. Ensure your system working safety.
We got TUV, API, WRAS, CE, ISO certification.
Standard conform to DIN, ASME, BS EN, JIS, API, AWWA.
Q: How could you provide quality service to our customers?
A: RKSfluid own 20 years experiences and more than 70 R&D engineers provide technical support, model selection and installation guidance for you.
