Factory Directly Sale BS EN1092-2 Ductile Iron DN50 DN100 Soft seated GGG50 Flange Flap Valve Price List
- Series: RKSfluid Flap Valve
- Port Size: DN50-DN600
- Pressure: PN10, PN16
- Temperature: -20℃ ~ +80℃
- Medium: Water
- Body: Ductile Iron: GGG50
- Flange Standard: EN1092-2
- Certificate: CE ,WRAS,API,ISO9001:2015,OHSAS18001:2007
- Tide Proof Swing Non Return Bottom Flap Valve
The flap valve normally be used as water conservancy facility. It is a one-way valve installed at the outlet of a riverside drainage pipe. When the river tide level is higher than the outlet, and the pressure is greater than the pressure inside the pipe, the flap automatically closes to prevent the river tide from backing up into the drainage pipe.
When the pressure inside the pipe is greater than the pressure outside of the flap then it opens and the medium inside the pipe is discharged, when the pressure from the drainage is released it will close. Thus preventing debris from the outside entering the pipe.
| Size | DN50-DN600 |
| PN | PN10/PN16 |
| Madium | Water |
| Temperature | -20°C~+80°C |
 |
Tag:
flap valve
,flap valve check valve
,Swing Check Valve
,ductile iron check valve
,ductile iron flap valve
,ductile iron body
